| Model: AW- | 25BL3-HDB |
| Type | Heating & Cooling |
| Water Volume & Cooling Time From 25℃ to 5℃ (Ambient Temp.: 30℃) |
50L: ≤0.65h 100L: ≤1.35h 200L: ≤2.7h 300L: ≤4.1h 500L: ≤6.75h |
| Heating Water Temperature Range (℃) | 15~40 |
| Cooling Water Temperature Range (℃) | 4~30 |
| Heating Operating Ambient Temperature Range (℃) | -5~43 |
| Cooling Operating Ambient Temperature Range (℃) | 10~43 |
| [Cooling] Ambient Temperature (DB/WB): 35℃/-; Water Outlet: 27℃; Water Flow: 1.2m³/h | |
| Cooling Capacity (kW) | 2.41 |
| Power Input (kW) | 1.08 |
| EER | 2.23 |
| [Cooling] Ambient Temperature (DB/WB): 27℃/-; Water Outlet: 5℃; Water Flow: 1.2m³/h | |
| Cooling Capacity (kW) | 1.69 |
| Power Input (kW) | 1.03 |
| EER | 1.64 |
| [Cooling] Ambient Temperature (DB/WB): 15℃/-; Water Outlet: 5℃; Water Flow: 1.2m³/h | |
| Cooling Capacity (kW) | 2.01 |
| Power Input (kW) | 0.81 |
| EER | 2.48 |
| [Heating] Ambient Temperature (DB/WB): 27°C/24.3°C; Water Inlet: 26℃; Water Flow: 1.2 m³/h | |
| Heating Capacity (kW) | 4.07 |
| Power Input (kW) | 0.87 |
| COP | 4.68 |
| [Heating] Ambient Temperature (DB/WB): 15°C/12°C; Water Inlet: 26℃; Water Flow: 1.2 m³/h | |
| Heating Capacity (kW) | 2.86 |
| Power Input (kW) | 0.88 |
| COP | 3.25 |
| [Heating] Ambient Temperature (DB/WB): 27°C/24.3°C; Water Inlet: 38℃; Water Flow: 1.2 m³/h | |
| Heating Capacity (kW) | 3.56 |
| Power Input (kW) | 1.05 |
| COP | 3.39 |
| General Information | |
| Power Supply | 220-240V~/50Hz |
| Rated Power Input (kW) | 1.30 |
| Rated Current (A) | 5.65 |
| Water Pump Power (W) | 65 |
| Refrigerant | R32 |
| Comppressor Brand | HIGHLY |
| Throttling Device | EEV |
| Water Side Heat Exchanger | Titanium Heat Exchanger |
| Circulation Pump | Low-Voltage Centrifugal Anti-Corrosion Pump |
| Sterilization Device | UV Sterilizer (Optional) Ozone Sterilizer (Optional) |
| Water Filter | External Water Filter (Optional) |
| Display | LED Screen |
| Wi-Fi Function | Yes |
| Transport Wheels | Yes (Optional) |
| Carry Handles | Yes (Optional) |
| Quick Connectors | Yes |
| Water Pipe Connection (mm) | φ20 |
| Water Proof Class | IPX4 |
| Electricity Shock Proof | Class Ⅰ |
| Sound Pressure Level at 1m [dB(A)] | 48 |
| Sound Pressure Level at 10m [dB(A)] | 32 |
| Net Weight (kg) | 35 |
| Net Dimensions With Wheels [L×W×H (mm)] | 470×386×534 |
| The above data are for reference only, and the specific data are subject to actual product. | |
